Fox lift/leveling kit. (14 trd 4x4)

Discussion in 'Aftermarket Products, Reviews & Installation' started by 2W1TRD, Feb 21, 2018.

  1. 2W1TRD

    2W1TRD Member

    Looking for enough lift to fit 33s without rub. Front coilovers come with 2.5 in preload and the rear has an AAL (heavy duty) to support this monster RTT/bed rack/gear/, you know the essentials. Issues? Advice? Cautions? Message_1518913768758.jpg

    OR17TRD likes this.
  2. Avatar

    Tacoma Forum Sign Up!

    Join TacomaForum.com Today - It's Totally Free!

    Are you a Toyota truck fan? If so we invite you to join TacomaForum.com. Our site is specifically designed for you and it's a great place for Toyota Tacoma Fans to meet online.
    Once you join you'll be able to post messages, upload pictures of your truck, and have a great time with other Toyota Tacoma fans. Whether your an old timer or just bought your Tacoma you'll find that TacomaForum.com is a great community to join. Best of all it's totally free!

    Join TacomaForum.com Today! JOIN FOR FREE

  3. OR17TRD

    OR17TRD Well-Known Member

    With that set up you’ll be able to fit 285/75/16 or 285/70/17 tires on 0 or -6 offset wheels. I’m not sure what the offset on the FJ TRD wheels you where asking about is. Otherwise the biggest you can fit is 265/75/16 or 265/70/17.
    The 285/75/16’s will rub on the front mud flaps and when turning into a hard bump. There may be some trimming and cab mount chop required depending on how heavy you off-road.

    Tacoman112 and 2W1TRD like this.
  4. OP
    2W1TRD

    2W1TRD Member

    I plan on putting on the cab mount chop plates to help eliminate that rub during full lock and suspension compression. Just want to try to get enough tire to get the lil taco over intermediate trails (maybe a little more rough) without seeing tire through my hood lol. Not sure about the offset on those wheels either...time to research. Thanks again! You da man.

    OR17TRD likes this.
  5. OP
    2W1TRD

    2W1TRD Member

    15mm offset on those FJ trd wheels. No good?

  6. OR17TRD

    OR17TRD Well-Known Member

    Looks like the FJ wheels are 17x7.5” +14 offset and the 285/70/17 tire should work with removal of the front mud flap you will eliminate rubbing with turing into hard bumps with the cab mount chop. If they are +15 they will still clear the UCA any higher offset and you won’t clear the UCA.

    2W1TRD likes this.
  7. OP
    2W1TRD

    2W1TRD Member

    Good bye FJ wheels. Time for a better offset.

  8. OR17TRD

    OR17TRD Well-Known Member

    I’d find some with a 0 or -6 offset you like. The FJ wheels would probably work after trimming and cab mount chop if you really want them to work with 285/70/17 tires.

  9. OR17TRD

    OR17TRD Well-Known Member

    I’d rather have a good 16x8 0 or -6 offset wheels with the 285/75/16 you’ll have more tire less rim which is better off-road IMO.

    Tacoman112 and 2W1TRD like this.
  10. Tacoman112

    Tacoman112 Well-Known Member

    I have that RTT setup and currently using the FJ 16x8 with 0 offset 285/75/16. Using 5100s and Dakar. So far so good for me.

    OR17TRD likes this.
  11. spinnintaco

    spinnintaco Member

    Last edited: Mar 28, 2018
    cranito4to and mcklovin77 like this.
  12. spinnintaco

    spinnintaco Member

    cranito4to and mcklovin77 like this.
